General

Overall length(mm)      12300

Overall width(mm)       2550

Overall height(mm)       3830

Inner Height(mm)         2050

Wheelbase(mm)           6100

Overhang front/rear(mm)   2700/3500

G. V. W.(Kg)         18500

Luggage Space     11.7m³

Seats capacity   55 1 1 Seats

Engine

Model              Cummins ISL9E6 400

Type                6 cylinder, turbocharged, intercooler, diesel.

Displacement         8.9L

Max. power          291KW@2100rpm

Max. torque          1676NM@1400rpm.

Emission standard     Euro 6.

Transmission

Model    ZF6AP1700B , hydraulic intarder.

Axle

Front   Independent, 7T

Rear    DANA 13T

Suspension

Front 2 rear 4 air bellows, shock absorbers, ECAS kneeling system.

Steering

Servocom type, hydraulic.

Braking system

Full dry air dual circuit braking system, front and rear disc brakes, KNORR ABS/ASR/AEBS

Tires and wheels

Michelin 295/80R22.5. Aluminium rim

Fuel system

Fuel tank capacity:  425L, Stainless steel

DEF tank    45L

Electric system

System voltage/Battery      24V/200AH

Alternator   140A 150A

Instrument system  CAN system

Structure

Rectangle steel tube welding, monocoque, electrophoresis.

Doors

Front and real door,outer swing, pheumatic, remote control. One piece luggage comparment door.

A/C

35KW air conditioning

Independent heaing system. Defroster.

Standard Equipment

LDWS·Curtains·Electrically operated sunvisors·Electrically operated reaview mirror·Interior mirror· Reverse and get off monitor· Driver coat hanger·Resetable circuit brakers·Tool set·220V output and USB
