General

Overall length(mm)  12000

Overall width(mm)   2500

Overall height(mm)    3260

Inner Height(mm)    Front: 2540/Rear: 1920

Wheelbase(mm)         6000

Overhang front/rear(mm)   2680/3320

G. V. W.(Kg)     18000

Passenger capacity   34 seats 58 standing passengers

Engine

Model              Cummins ISB6.7E6 280B

Type                6 cylinder, turbocharged, intercooler, diesel.

Displacement         6.7L

Max. power          204KW@2100rpm

Max. torque          1082NM@1200-1400rpm.

Emission standard     Euro 6.

Transmission

Model    ZF6AP1200B , hydraulic intarder.

Axle

Front   DANA, 7.5T, Low floor.

Rear    DANA 13T

Suspension

Front 2 rear 4 air bellows, shock absorbers, anti-roll bar, ECAS kneeling system.

Steering

Servocom type, hydraulic.

Braking system

Full dry air dual circuit braking system, front and rear disc brakes, WABCO ABS/ASR

Tires and wheels

275/70R22.5.  Michelin.

Fuel system

Fuel tank capacity:  260L, Stainless steel

DEF tank    35L

Electric system

System voltage/Battery      24V/200AH

Alternator   80A*2 150A

Instrument system  CAN system

Structure

Rectangle steel tube welding, monocoque, electrophoresis.

Doors

Front and real double door, inner swing, pheumatic control.

A/C

35KW air conditioning

Independent heaing system. Defroster.

Standard Equipment

Driver side curtains·Electrically operated sunvisors·Electrically operated reaview mirror·Interior mirror·Reservere and get off monitor·Escape hatch·Driver coat hanger·Resetable circuit brakers·Tool set·Fabric seat covers. ·Programmable destination display·Inner display.
